Matrix備忘録

※Synapseのみで動作することに気づいたため修正した。

Matrix と Element を自分のサーバーで動かす

以下の2つの記事が参考になりました。ありがとうございます。

MatrixでDiscord/Slackを所有する
先日のDiscordの障害は華金を電脳空間で過ごそうと決めていた人々を絶望の淵に叩き込んだ。きょうびオンラインゲームをやるとなったらボイスチャットはほぼ必須であり、とりわけDiscordは当該の分野で支配的な地位を占めている。ちなみに、僕は独りで黙々とCounter-Strike2のランクマッチを回していたので関係なかった。静謐。 しかし他に寄辺のない異常独身男性が集結せしDiscordサーバを運用している立場としては、一つのサービスの死がコミュニケーションの喪失を引き起こしかねない現状はまったく好ましくない。彼らは他のSNSをあまり使わない。以前から代替ツールを模索してはいたが、企業運営の類似サービスでは面白みに欠けるし、かといってセルフホスト型だと「そのためだけのアカウント」が余分に増えてしまう。なにしろ従来の形態ではサーバごとに別のアカウントを作らなければならないのだ。
MatrixでDiscord/Slackを所有する favicon https://riq0h.jp/2023/10/01/203658/
MatrixでDiscord/Slackを所有する
Matrix自鯖メモ(docker-compose, synapse, Caddy)
Matrix自鯖メモ(docker-compose, synapse, Caddy) favicon https://zenn.dev/hidaruma/articles/4ef72417d960d7
Matrix自鯖メモ(docker-compose, synapse, Caddy)

以下はすでに docker で caddy が動作している環境の話となっています。ホスト名もすでに存在している前提になっています。

利用ポート

連合のために8448ポートが使われるのでポート開放しておくこと。

80,443ポートはCaddyで利用するために開放してあるものとする。

内部ポート8008につなげるポートとして10088を利用した。

compose.yml を作成する

ここでは matrix -> docker というディレクトリ構成下に compose.yml ファイルを作成した。

└── matrix
└── docker
└── compose.yml (これを編集する)
matrix/docker/compose.yml
services:
synapse:
restart: always
image: matrixdotorg/synapse:latest
volumes:
- ../data:/data
environment:
- SYNAPSE_SERVER_NAME=自分のMatrixサーバーのホスト名
- SYNAPSE_REPORT_STATS=yes
ports:
- "10088:8008"
networks:
- external_network
- internal_network
networks:
external_network:
internal_network:
internal: true

Synapse 設定ファイル群の生成

Synapseの設定ファイル群を生成するために compose.yml ファイルがあるディレクトリで docker compose run --rm synapse generate を実行する。

上記の compose.yml ではそのファイルがある上のディレクトリに設定ファイル・ディレクトリ群(data db redis)が生成される。(volumesのディレクトリ指定に注意)

設定ファイル編集のため一旦コンテナを停止する。docker compose down

homeserver.yamlの編集

次に上位ディレクトリに生成された設定ファイルを編集する。vi ../data/homeserver.yaml

└── matrix
├── data
│   └── homeserver.yaml (これを編集する)
└── docker
└── compose.yml

以下は生成直後のもの。“XXXX” には自動生成されたものが入る。

matrix/data/homeserver.yaml
# Configuration file for Synapse.
#
# This is a YAML file: see [1] for a quick introduction. Note in particular
# that *indentation is important*: all the elements of a list or dictionary
# should have the same indentation.
#
# [1] https://docs.ansible.com/ansible/latest/reference_appendices/YAMLSyntax.html
#
# For more information on how to configure Synapse, including a complete accounting of
# each option, go to docs/usage/configuration/config_documentation.md or
# https://element-hq.github.io/synapse/latest/usage/configuration/config_documentation.html
server_name: "XXXX"
pid_file: /data/homeserver.pid
listeners:
- port: 8008
tls: false
type: http
x_forwarded: true
resources:
- names: [client, federation]
compress: false
database:
name: sqlite3
args:
database: /data/homeserver.db
log_config: "/data/XXXX.log.config"
media_store_path: /data/media_store
registration_shared_secret: "XXXX"
report_stats: true
macaroon_secret_key: "XXXX"
form_secret: "XXXX"
signing_key_path: "/data/XXXX.signing.key"
trusted_key_servers:
- server_name: "matrix.org"
# vim:ft=yaml

このままではユーザー登録や連合時の検索、外部からのサーバー追加などが機能しないので以下を追記する。

enable_registration: true
enable_registration_without_verification: true
allow_public_rooms_over_federation: true
allow_public_rooms_without_auth: true
enable_room_list_search: true

ちなみにこの状態だと自由に登録し放題なので注意。enable_registrationfalse にすれば自由に登録はできなくなる。

その後 compose.yml のあるディレクトリに戻り docker compose up -d を実行する。docker ps で正しく起動できているか確認。

チャットでリンクが貼られたときにリンクカードが作られるようにする

サンプルの記述は以下のとおり。rangeは自分の環境に合わせて変更する。blacklist関係は無駄な負荷を防ぐためのもの。

url_preview_enabled: true
url_preview_ip_range_blacklist:
- "127.0.0.0/8"
- "10.0.0.0/8"
- "172.16.0.0/12"
- "192.168.0.0/16"
- "100.64.0.0/10"
- "192.0.0.0/24"
- "169.254.0.0/16"
- "192.88.99.0/24"
- "198.18.0.0/15"
- "192.0.2.0/24"
- "198.51.100.0/24"
- "203.0.113.0/24"
- "224.0.0.0/4"
- "::1/128"
- "fe80::/10"
- "fc00::/7"
- "2001:db8::/32"
- "ff00::/8"
- "fec0::/10"
url_preview_url_blacklist:
# blacklist any URL with a username in its URI
- username: "*"
# blacklist all *.google.com URLs
- netloc: "google.com"
- netloc: "*.google.com"
# blacklist all plain HTTP URLs
- scheme: "http"
# blacklist http(s)://www.acme.com/foo
- netloc: "www.acme.com"
path: "/foo"
# blacklist any URL with a literal IPv4 address
- netloc: '^[0-9]+\.[0-9]+\.[0-9]+\.[0-9]+$'

Element の準備

自分のサーバー上でMatrixクライアントも動作させるために Element を設置する。

GithubのElementのreleasesページから tar.gz ファイルを取得する。

Releases · element-hq/element-web
A glossy Matrix collaboration client for the web. Contribute to element-hq/element-web development by creating an account on GitHub.
Releases · element-hq/element-web favicon https://github.com/element-hq/element-web/releases
Releases · element-hq/element-web
Terminal window
wget https://github.com/element-hq/element-web/releases/download/v1.11.91/element-v1.11.91.tar.gz

サーバー上のElementのルートとしたいディレクトリ上にtar.gzファイルを展開しその中身を設置する。ファイルの中にconfig.sample.json があるのでそれを config.json に名前を変更して自分のサーバー用に編集する。

config.json
{
"default_server_config": {
"m.homeserver": {
"base_url": "https://自分のMatrixサーバーのホスト名",
"server_name": "自分のMatrixサーバーのホスト名"
},
"m.identity_server": {
"base_url": "https://vector.im"
}
},
"disable_custom_urls": false,
"disable_guests": false,
"disable_login_language_selector": false,
"disable_3pid_login": false,
"force_verification": false,
"brand": "Element",
"integrations_ui_url": "https://scalar.vector.im/",
"integrations_rest_url": "https://scalar.vector.im/api",
"integrations_widgets_urls": [
"https://scalar.vector.im/_matrix/integrations/v1",
"https://scalar.vector.im/api",
"https://scalar-staging.vector.im/_matrix/integrations/v1",
"https://scalar-staging.vector.im/api",
"https://scalar-staging.riot.im/scalar/api"
],
"default_widget_container_height": 280,
"default_country_code": "JP",
"show_labs_settings": false,
"features": {},
"default_federate": true,
"default_theme": "light",
"room_directory": {
"servers": ["matrix.org"]
},
"enable_presence_by_hs_url": {
"https://matrix.org": false,
"https://matrix-client.matrix.org": false
},
"setting_defaults": {
"breadcrumbs": true
},
"jitsi": {
"preferred_domain": "meet.element.io"
},
"element_call": {
"url": "https://call.element.io",
"participant_limit": 8,
"brand": "Element Call"
},
"map_style_url": "https://api.maptiler.com/maps/streets/style.json?key=fU3vlMsMn4Jb6dnEIFsx"
}

Caddyfile の設定

現在のサーバーは Caddy が動作しているのでそこからリバースプロキシする設定を追記する。

webサーバーソフトごとのリバースプロキシ設定はドキュメントに書かれている。

Configuring a Reverse Proxy - Synapse
Configuring a Reverse Proxy - Synapse favicon https://matrix-org.github.io/synapse/latest/reverse_proxy.html
自分のMatrixサーバーのホスト名 {
tls {
on_demand
}
reverse_proxy /_matrix/* localhost:10088
reverse_proxy /_synapse/client/* localhost:10088
file_server
root * 「Elementのマウント先ディレクトリ」
encode zstd gzip
}
自分のMatrixサーバーのホスト名:8448 {
tls {
on_demand
}
reverse_proxy /_matrix/* localhost:10088
}

Element のマウント先ディレクトリは compose.yaml ファイルの方で設定した。

compose.yaml
volumes:
- type: bind
source: Elementがあるディレクトリ(ローカル)
target: Elementのマウント先ディレクトリ(コンテナ内)
他の部分は省略

Caddy を再起動した後に自分のMatrixサーバのアドレスからElementが起動するか確認する。

最後に compose.yml があるディレクトリに戻りdocker compose up -dを実行して Synapse を起動する。

注意とまとめ

管理者用メールのためのSMTP設定などはしていない状態なのであくまでテスト用です。

Elementの使い方は割愛します。
